Chem-Crete® PAVIX® CCC® 100

Chem-Crete® PAVIX® CCC® 100, is a patented Dual-Crystalline, penetrating concrete and masonry sealer. It is a water-based and environmentally-friendly waterproofing product that combines hygroscopic and hydrophilic crystals for pore-blocking function, and hydrophobic material for pore lining. It is designed to protect surfaces from the delaminating effects of water, moisture saturation, freeze/thaw, Alkali Silica Reactions (ASR), chloride-ion penetration and ice adhesion. PAVIX is ideal for exterior or interior concrete and masonry surfaces and can be applied to both positive or negative hydrostatic pressure sides of concrete. PAVIX enhances concrete sustainability, significantly reduces maintenance costs and increases concrete and masonry life cycles.



Request a Quote
Category:

Description

  • Topical concrete protection for green and cured concrete.
  • Patented dual-crystalline technology that works through two actions: pore blocking and pore lining.

What It Is

Concrete Protection Against Water, Moisture & Ice and Durability Solution by Pore Blocking and Lining Using Topical Treatment for Green & Cured Concrete for Airports, Highways & Bridges Structures.

When to Use It

Use on green or cured concrete exposed to water, de-icing salts, freeze/thaw conditions or chloride-related durability concerns.

Pair with MCE for new mix protection; repair products where deterioration already requires repair.

Key Benefits

  • One Application
    Designed as a one-time treatment.
  • Non-Film-Forming
    No surface coating to peel or wear away.
  • Zero VOC
    No silane / siloxane chemistry.

Advantages, Features & Benefits

  • Application on Fresh and Hardened Concrete: Suitable for use on both green (freshly placed) concrete and fully cured concrete surfaces.
  • Long-Term Internal Waterproofing: Helps restrict water penetration and moisture movement through concrete, providing protection against hydrostatic pressure from either side of the structure.
  • Significantly Lower Water Permeability: Testing at 200 psi (1.38 MPa), in accordance with CRD-48-92, demonstrates a reduction in water permeability by 2 to 3 orders of magnitude.
  • Advanced Water-Repellent Performance: Develops hydrophobic properties that help prevent water, jet fuel, and oil from wetting and saturating treated concrete. The treatment increases the water contact angle on concrete surfaces to greater than 90°, with the product page illustrating a contact angle of 105° on treated concrete.

Uses

  • Airports: Runways, taxiways, and aircraft parking aprons.
  • Roads and Highways: Concrete pavements, bridges, and roadside barriers.
  • Concrete Infrastructure: Tunnels, parking structures, dams, and retaining walls.
  • Seaports and Marine Facilities: Concrete seawalls, docks, and piers exposed to challenging environmental conditions.
  • Railway Infrastructure: Concrete railway ties and sleepers, as well as station platforms.
  • Exterior and Interior Flatwork: Parking areas, driveways, sidewalks, and patios.
  • Precast Concrete Products: Tilt-up concrete walls, manholes, and precast pipes.

Packaging

Product Packaging
CHEM-CRETE PAVIX CCC100 1 GAL (3.79 LITER) JUG
5 GAL (18.9 LITER) PAIL
55 GAL (208 LITER) DRUM
265 GAL (1000 LITER) TOTE


Technical

Physical Properties @ 77 oF (25 oF)
Specific Gravity 1.1 – 1.2
Viscosity 2.4 centipoises
Freezing Point 25ºF (-3.89°C)
Boiling Point 219ºF (104 °C)
Color Clear
Environmental Hazards None
Drying Time 2 – 3 hours
Odor None
Toxicity None
Fumes None
Flammability None
  Product Performance: PAVIX is tested according to the following test standards:
  • CRD-48-92 US Army Corps of Engineers Standard Test Method for Water Permeability of Concrete
  • ASTM D6489-99 Determining the Water Absorption of Hardened Concrete Treated with a Water Repelling Coating.
  • ASTM C642-97 Standard Test Method for Density, Absorption, and Voids in Hardened Concrete
  • ASTM C1202-91 Electrical Indication of Concrete’s Ability to Resist Chloride Ion Penetration.
  • AASHTO T260 Sampling and Testing for Chloride Ion in Concrete and Concrete Raw Materials
  • AASHTO T277 Electrical Indication of Concrete’s Ability to Resist Chloride Ion Penetration
  • AASHTO T259-00 Resistance of Concrete to Chloride Ion Penetration
  • ASTM C1218 Water-Soluble Chloride in Mortar and Concrete.
  • ASTM C672-98 Scaling Resistance of Concrete Surfaces Exposed to Deicing Chemicals
  • ASTM C457-98 Microscopical Determination of Parameters of the Air-Void System in Hardened Concrete
  • MIL-STD-810G Fungal Resistance According to Test Method Standard for Environmental Engineering Considerations and Laboratory Tests
  • ASTM D4541-95 Pull-Off Strength of Coatings Using Portable Adhesion Testers
  • ASTM C1583 Bond Strength or Tensile Strength of Overlay Materials by Direct Tension
  • ASTM F609-96 Standard Test Method for Using a Horizontal Pull Slipmeter (HPS)
  • ASTM E303-93 Measuring Surface Frictional Properties Using the British Pendulum Tester
  • ASTM D7234 Standard Test Method for Pull-Off Adhesion Strength of Coatings on Concrete Using Portable Pull-Off Adhesion Testers
  • ASTM C666-97 Resistance of Concrete to Rapid Freezing & Thawing
  • ASTM C1567 Standard Test Method for Determining the Potential Alkali-Silica Reactivity of Combinations of Cementitious Materials and Aggregate (Accelerated Mortar-Bar Method)

Application

Limitations: Do not apply PAVIX in the following cases:
  • If the concrete surface temperature falls below 40°F (5°C).
  • If the area has been previously treated with sealing agents unless the sealers are removed by chemical or mechanical means.
Application: Fully cured or existing concrete: Repair and seal joints, cracks, and voids greater than 1/16th inch prior to the application. Concrete surfaces must be clean and sound prior to application of the product. Proper cleaning will open the surface pores and capillaries to enhance the penetration process. Compressed air or mechanical sweepers can be used to remove dust and loose particles from the surface. Flushing the area to be treated with water can improve the cleaning process. However, for heavily contaminated areas special concrete cleaning agents such as Chem-Crete CONCLEAN CCC060 can be used to remove dirt, grease, and oil from those areas.   Broom finished concrete should be lightly dampened (NO STANDING WATER) prior to application to eliminate potential overlap lines.   Coverage: Apply at an average coverage rate of 150-200 ft2/gal (3.7-4.9 m2/liter) in one coat. Green/Plastic Concrete:
  1. Only consider an application when concrete finishing is completed and the disappearance of bleed water.
  2. Concrete should not be in duress and should be curing normally.
  3. Apply PAVIX uniformly and at an average coverage rate of 200 ft2/gallon (4.9 m2/L).
  4. DO NOT allow the PAVIX to puddle or pool.
  5. Application of membrane-forming curing compound within 20 minutes from the initial PAVIX application.
  6. Apply the membrane curing compound at the manufacturer’s recommended coverage rate.
Cleaning: all tools and equipment must be cleaned with clean water immediately after use.

Storage

Two-year shelf life when stored in its original, unopened container in a cool, dry place. Always agitate the product before using. DO NOT ALLOW PRODUCT TO FREEZE. Repeated freezing and thawing may cause damage to the product.

Safety

As with all construction chemical products, adequate precautions and care must be taken during usage and storage.  Avoid direct contact with foodstuff, eyes, skin, and mouth.  Any contacted areas should be washed thoroughly with clean running water and soap. Always wear protective goggles and gloves. In case of eye contact, flush for fifteen minutes with warm water. If eye irritation persists, seek medical attention. In case of ingestion or swallowing, drink 2 glasses of clean water and seek medical attention. KEEP OUT OF REACH OF CHILDREN.

Warranty

LIMITED WARRANTY:   International Chem-Crete warrants that, at the time and place we make shipment, our materials will be of good quality and will conform to our published specifications in force on the date of acceptance of the order. DISCLAIMER: The information contained herein is included for illustrative purposes only, and to the best of our knowledge, is accurate and reliable. International Chem-Crete cannot, under any circumstances, make any guarantee of results or assume any obligation or liability in connection with the use of this information. As International Chem-Crete has no control over product usage, it is recommended that the product be tested to determine suitability for a specific application and/or that our information is valid in a particular circumstance. Responsibility remains with the architect or engineer, contractor and owner for the design, application and proper installation of each product. Specifier and user shall determine the suitability of products for specific application and assume all responsibilities in connection therewith. Any liability is limited to the replacement of material if proven faulty. AM010322-05
